A-20 Stereo Amfi
50W Stereo Amplifier with Direct Energy Design and Aluminium Panels
Simplicity. Finesse. Performance.
The A-20 Direct Energy Design amplifiers with Symmetrical Construction offer class-leading, high quality sound, wrapped in understated, technical elegance.
The polished, brushed aluminum front panel comes with control knobs for Volume, Bass/ Treble/ Balance and Input Source selection. A range of tactile buttons finetune Loudness, Direct Mode and Speaker A/B. The rear panel provides immediate connectivity to Aux-In, Network, Recorder, Speaker A + B and 'Source Direct Mode' devices.
Product highlights at a glance:
- 50W + 50W (4 Ω, 20Hz - 20kHz)
- Phono MM input
- Remote Control/ Motorised Volume
- Auto Power Down.
Main Features
-
Output Power per Channel 50W
-
Impedance at Output Level • 4 Ω - 16 Ω (A / B)
• 8 Ω - 32 Ω (A + B)
• 4 Ω - 16 Ω (Bi-wiring) -
Number of Channels 2
-
Input Connections • SACD/CD
• Phono (MM)
• Aux
• Network
• Recorder
• Tuner
-
Output Connections • Recorder
• Phones -
Remote Control Yes
Input & Output connections
-
Headphone Yes
-
Large speaker terminals Yes
-
Phono Input Yes
-
Speaker A/B Yes
Audio Features
-
Bass/Treble Tone Controls Yes
-
'DIRECT' Switch Yes
-
Loudness (+) Yes
-
Muting Yes
-
Source Direct Yes
Power Output
-
Power output per channel 50 W
-
Condition 20 Hz - 20 kHz, 4Ω, 0.1 % КНИ
-
Rated Power Output 50 W per channel
-
Power Requirements AC 220 - 230 В / 50 Гц
-
Power Consumption (in use / standby) 135 W / 0.30 W
-
Auto Power Down Yes
Construction
-
Design - Direct Energy Design Amp
- Symmetrical Power Amp
- Clean Ground Construction
- Isolated Power Supply
- Source Direct Mode
- Trans-Stabiliser
- Speaker A, B, A+B Selector
- Aluminium Panels
- Auto Power Down
Amplifier Specifications
-
Dimensions (W x H x D) 435 x 128 x 360 mm
-
Weight 7.2 kg
| User manual | 01/06/2012 | Turkish | 2424 KB | View in browser|Download |
