ASW 10CM S2 Subwoofer
A beautifully versatile and powerful subwoofer that is designed to complement the rest of the CM Series in audio delivery and aesthetics.
ASW10CM S2 now features the option of either Gloss Black or
Satin White finish, with a light gray grille, to better match the rest of the
CM Series.
Underneath the stylish exterior lies the power and performance for which Bowers
& Wilkins subwoofers are renowned. A 10" (250mm) Kevlar® driver is
controlled by a highly efficient 500W audiophile Class D amplifier with switch
mode power supply.
The result is that ASW10CM S2 can deliver the precise bass effects and power
you might need in any situation, for any sized room or home cinema system.
|
Woven Kevlar |
|
|
Flowport |
|
|
Technical features |
Paper/Kevlar® cone long throw driver |
|
Description |
Active closed-box subwoofer system |
|
Drive units |
ø250mm (10 in) paper/Kevlar® cone long-throw |
|
Frequency range |
-6dB at 18Hz and 25/140Hz adjustable (EQ at A) |
|
Frequency response |
±3dB 25Hz – 40/140Hz adjustable (EQ at A) |
|
Bass Extension |
-6dB at 18Hz (position A) |
|
Amplifier |
|
|
Power output: |
500W |
|
Rated power consumption: |
94W |
|
Standby power consumption: |
0.8W |
|
Input impedance: |
33kV |
|
Signal / noise: |
>80dB |
|
Functions: |
Input level (line in) |
|
Inputs: |
Line In (RCA Phono) |
|
Low-pass filter |
Active 4th-order, variable cut-off frequency |
|
Dimensions |
Height: 325mm (12.8 in) (not including feet) |
|
Net weight |
15.5kg (34.4 lb) |
|
Finishes |
|
|
Cabinet: |
Gloss Black |
|
Grille: |
Black |
|
Ligne (RCA Line In) |
