ASW 610 Subwoofer
The ASW610's long-throw 250mm driver allows it to move the large volumes of air needed for high-quality low-frequency output, and its audiophile-standard 200W Class D amplifier keeps the compact unit running cool.
The ASW610 subwoofer presents a very happy medium between
the more diminutive ASW608 and the all-out power of the ASW610XP. Its
long-throw 250mm driver allows the ASW610 to move the large volumes of air needed
for high-quality low-frequency output, and its audiophile-standard 200W Class D
amplifier keeps the compact unit running cool, even when the music or movie
action is whipping up a storm.
In all of the 600 Series subwoofers, the bass driver diaphragms are constructed
from a rugged, finely-tuned mix of paper pulp, Kevlar® fibres and resin, which
provides the stiffness needed to withstand the tremendous physical forces
exerted by the voice coil and pressures inside the cabinet.
Ultra-solid construction delivers slamming bass, drum kicks, and special movie
effects. Deformation is minimised; bass precision, power and enjoyment are
maximised.
|
Crossover Tuning |
|
|
Mushrooms |
|
|
Description |
Active closed-box subwoofer system |
|
Drive unit |
ø250mm (10 in) paper/Kevlar® cone long-throw |
|
Frequency range |
-6dB at 20Hz and 25/140Hz adjustable (EQ at A) |
|
Frequency response |
±3dB 27Hz – 40/140Hz adjustable (EQ at A) |
|
Bass Extension |
-6dB at 20Hz (position A) |
|
Power output: |
200W |
|
Rated power consumption: |
40W / 0.5W standby |
|
Input impedance: |
33kΩ |
|
Signal / noise: |
>90dB |
|
Functions: |
Input level (line in) |
|
Inputs: |
Line In (RCA Phono) |
|
Dimensions |
Height: 310mm (12.2 in) not including feet |
|
Net weight |
12.5kg (27.6 lb) |
|
Finishes |
Black |
