ASW 610XP Subwoofer
The ASW610XP, the most powerful of the 600 Series subwoofers, delivers the finishing touch – or finishing thump – to a hi-fi or home theatre system for larger rooms.
The ASW610XP, the most powerful of the 600 Series
subwoofers, delivers the finishing touch – or finishing thump – to a hi-fi or
home theatre system for larger rooms. Serious bass power is developed in a
compact cabinet thanks to the unit’s 500W amplifier, long-throw 250mm driver.
Equipped with audiophile-standard Class D circuitry, the unit remains cool and
efficient under pressure.
In all of the 600 Series subwoofers, the bass driver diaphragms are constructed
from a rugged, finely-tuned mix of paper pulp, Kevlar® fibres and resin, which
provides the stiffness needed to withstand the tremendous physical forces
exerted by the voice coil and pressures inside the cabinet.
Ultra-solid construction delivers slamming bass, drum kicks, and special movie
effects. Deformation is minimised; bass precision, power and enjoyment are
maximised.
|
Crossover Tuning |
|
|
Mushrooms |
|
|
Description |
Active closed-box subwoofer system |
|
Drive unit |
ø250mm (10 in) paper/Kevlar® cone long-throw |
|
Frequency range |
-6dB at 18Hz and 25/140Hz adjustable (EQ at A) |
|
Frequency response |
±3dB 25Hz – 40/140Hz adjustable (EQ at A) |
|
Bass Extension |
-6dB at 18Hz (position A) |
|
Amplifier |
Power output: 500W |
|
Rated power consumption: |
98W / 1W standby |
|
Input impedance: |
33kΩ |
|
Signal / noise: |
>90dB |
|
Functions: |
Input level (line in) |
|
Inputs: |
Line In (RCA Phono) |
|
Dimensions |
Height: 325mm (12.8 in) not including feet |
|
Net weight |
15.5kg (34.4 lb) |
|
Finishes |
Black |
