CM 8 S2 Kule Hoparlör

113.538,81 TL
Stok Kodu
EJKQSUX9
Fiyat
2.750,85 USD + KDV
CM 8 S2


True floorstander performance from a seriously slim speaker. CM8 S2 will slip into any room, yet delivers power and precision from three Kevlar drivers and a Decoupled Double Dome tweeter.



With a cabinet just 165mm wide, CM8 S2 will fit in any room. And thanks to concealed fixings and a minimalist, magnetic and protective tweeter grille, CM8 S2 combines subtle stylish looks with modern, practical design.

Key to its slim profile is the use of two 130mm Kevlar bass drive units combined with a 130mm Kevlar FST midrange. The FST driver uses "surroundless" suspension to improve crossover with the tweeter, give a faster response and improve accuracy through the midrange.

Of course, CM8 S2 isn't designed solely to deliver power in a smaller form factor. With an FST midrange and Decoupled Double Dome Tweeter for increased rigidity and isolation from the cabinet, CM8 S2 is also designed for precise audio response.



Woven Kevlar

Flowport

Technical features

Nautilus tube loaded Decoupled Double Dome aluminium tweeter
Kevlar® brand fibre cone FST midrange
Flowport™

Description

3-way vented-box system

Drive units

1x ø25mm (1 in) Decoupled Double Dome aluminium high-frequency
1x ø130mm (5 in) woven Kevlar® cone FST midrange
2x ø130mm (5 in) paper/Kevlar® cone bass

Frequency range

-6dB at 43Hz and 50kHz

Frequency response

48Hz - 28kHz ±3dB

Dispersion

Within 2dB of reference response
Horizontal: over 60º arc
Vertical: over 10º arc

Sensitivity

88dB spl (2.83V, 1m)

Harmonic distortion

2nd and 3rd harmonics (90dB, 1m)
<1% 100Hz - 22kHz
<0.5% 300Hz - 20kHz

Nominal impedance

8Ω (minimum 3.1Ω)

Crossover frequencies

350Hz, 4kHz

Recommended amplifier power

30W - 150W into 8Ω on unclipped programme

Max. recommended cable impedance

0,1 Ω

Dimensions

Height: 924mm (36.4 in) cabinet only
Width: 165mm (6.5 in) cabinet only
252mm (9.9 in) including plinth
Depth: 277mm (10.9 in) cabinet, grille and terminals only
298mm (11.7 in) including plinth

Net weight

19.5kg (43 lb)

Finishes



Cabinet:

Rosenut
Gloss Black
Satin White

Grille:

Black
Grey (Satin White only)
