The NS-SW700 subwoofer meets the challenge of providing an ideal balance between tight sounds (with crisp, fast attack) and deep sounds (with a spacious feeling). Although these two types of sounds, by definition, tend to oppose each other, this subwoofer is capable of accurately rendering the tone intervals of all kinds of sounds, so the music is ideally balanced. Finally, the enjoyment derived from the NS-SW700 is not restricted to your ears — with it's impressive power it lets you feel the music, too
- 25cm (10”) 300W subwoofer with Advanced YST II and QD-Bass technology
- Linear Port enhances bass while minimising extraneous noise
- BASS (Bass Action Selector System)
Ideally Balanced Sound
The NS-SW700 subwoofer meets the challenge of providing an ideal balance between tight sounds (with crisp, fast attack) and deep sounds (with a spacious feeling). Although these two types of sounds, by definition, tend to oppose each other, this subwoofer is capable of accurately rendering the tone intervals of all kinds of sounds, so the music is ideally balanced.Finally, the enjoyment derived from the NS-SW700 is not restricted to your ears — with it's impressive power it lets you feel the music, too.
PWM Digital Drive High Efficiency Amplifier
The NS-SW700 subwoofer delivers high power outputs at deep bass levels, with excellent stability and low power consumption, even with their compact cabinets.
This is made possible by a power amplifier that delivers stable power output with high efficiency while minimising power consumption and heat production.
It does not require an output filter coil, resulting in extremely low noise and distortion. High speed transient response is also excellent.
Advanced YST II for Awesome Deep Bass
Yamaha's Advanced YST II (Yamaha Active Servo Technology II) uses Advanced Negative Impedance Converter (ANIC) circuits to maintain excellent linearity.
This means more stable and accurate low range response and higher sound pressure levels, for more natural and energetic bass reproduction.
QD-Bass Technology Allows Free Placement
QD-Bass (Quatre Dispersion Bass) technology uses down-firing drivers with square, pyramid-shaped reflective plates to radiate the sound efficiently in four horizontal directions.
It provides extraordinary power and smooth frequency response from an extremely compact unit. It also allows greater freedom of placement, since the sound radiates with equal effectiveness in all directions.
Linear Port
The Linear Port provides smooth bass response while minimising extraneous noise.
BASS
The BASS (Bass Action Selector System) function lets you switch between Movie and Music modes, providing the optimum frequency response in each case.
|
|
||
|---|---|---|
| Specifications | ||
| Type | Advanced YST II and QD-Bass Subwoofer | |
| Driver | 25cm cone | |
| Dynamic Power | 300 W | |
| Frequency Response | 20-160 Hz | |
| Advanced YST | Advanced YST II | |
| QD-Bass Technology | Down-firing | |
| High-Efficiency Power Amplifier | Yes | |
| Linear Port | Yes | |
| BASS (Bass Action Selector System) | Yes | |
| Standby Power Consumption | 0.5 W | |
| Dimensions (W x H x D) | 406 x 445 x 406 mm | |
| Weight | 21 kg | |
