S 622

2-way bookshelf speaker

Space-saving Danish design

Affordable high-performance audio technology

Design

The Jamo S 622 offers a beautiful and compact design without sacrificing audio performance, making it a great choice for use as a stereo speaker or as a surround speaker in your home cinema system.Available in three different finishes, White Ash, Dark Apple and Black Ash, the S 622 blends into your unique home decor without taking up a lot of space. A built-in keyhole mounting slot allows for quick and simple wall-mounting. The front fabric grilles are easily removable, allowing you to decide which look you prefer.

Technology

1-inch (25 mm) soft dome tweeter/4-inch (102 mm) aluminized woofer.

Bass-reflex design with flared, rear-firing port: Increases system efficiency and bass output.

Waveguide: A unique tweeter faceplate that provides more uniform dispersion in the critical frequency range of 2-10 kHz. Dynamics and clarity are enhanced while distortion is significantly reduced.

Centre-plug: Replaces the typical dust cap and eliminates cone breakup, for a woofer with faster "attack" and tighter, more natural bass.

Aluminized woofers: Increases driver cone rigidity for solid bass reproduction.

5-way binding posts: Allows for multiple connection options with wire up to 12 gauge (AWG).

System Type 2 Way Bass Reflex

Impedance 6

Weight (Kg/lb) 6.7 / 14.771

Tweeter (mm/in) 25 / 1

Woofer (mm/in) 102 / 4

Product dimensions (mm/in, HxWxD) 240 x 133 x 210 / 9.4 x 5.2 x 8.3

Frequency Response (Hz, +/-3dB) 80-20,000

Power Handling (Watts Long/Short Term) 80 / 130

Sensitivity (dB, 2.8V/1m) 87

Crossover Frequency 2500

Finish Black Ash , White Ash , Dark Apple
